nPZero
power-saving IC

IPMIC-Both-Front-Back-web2

Offers up to 90% reduction in power consumption

Datasheet

View and download the datasheet for the nPZero power-saving IC.

nanowatt

consumption

up to 90%

reduction

The nPZero power-saving IC, is set to revolutionize the power consumption of battery and energy-harvesting powered devices, offering install-and-forget capabilities

Introduction

The nPZero power-saving IC with the nPZero architecture redefines low power.

The nPZero architecture represents a completely new way of thinking when designing battery-constrained systems. An active system without an active microcontroller is now a possibility:

The nPZero power-saving IC can operate the entire system without an active host, e.g., MCU, processor, or wireless SoC. It can take over the controller role and manage peripherals like sensors, and later hand the controller role back to the host based on user-configurable rules. This enables the power-hungry host to be completely shut down while keeping functions and responsiveness intact. As a true power manager, the peripherals’ power consumption is also optimized.

nPZero-power-saving-IC-1200x627

nPZero EVB waiting list

Join the waiting list and be notified when the EVB is available

nPZero IC explained

The nPZero power-saving IC explained in short videos

Blog-front-page-for-videos-1200x627--1

Main functions and features

What differentiates the nPZero power-saving IC from other products on the market:

  • Unique low power

    consumption through a full subthreshold design.

  • Compatible

    with a range of peripherals (I2C and SPI) and hosts (MCU, processor, or wireless SoC).

  • Standalone operation

    enables the host to be powered off while the system is still operating. Peripherals are managed without an active host. The nPZero IC takes over the controller role in the system; powering up, configuring, and reading peripherals. When required, the controller role is handed back to the host.

  • Intelligent functions

    with the ability to act dependent on user-defined rules. A programmable logic with a reconfigurable state machine that enables actions based on events. For example, sensor values above/below a set threshold can trigger actions, including, e.g., waking up the host to initiate wireless communication.

  • Peripheral power optimization

    by individual power cycling of peripherals to ensure the lowest possible power consumption.

  • Internal low-power memory

    to store commands, peripheral and host configurations, and sensor values.

  • Internal clock

    with different alternatives depending on accuracy requirements.

  • Configurable

    for specific applications with API for programming via the host.

EVB Block Diagram - REV09
